SLIDE 'ON/OFF' SWITCHThe tool is switched 'ON' by the slide switch located on the topside of the motor housing.TO TURN THE TOOL 'ON', slide the switch button forward.TO TURN THE TOOL 'OFF', slide the switch button backward.ELECTRONIC FEEDBACKYour tool is equipped with an internal electronic feedback system that provides a “soft start”, which will reduce the stresses that occur from a high torque start. The system also helps to keep the preselected speed virtually constant between no-load and load conditions.VARIABLE SPEED CONTROL DIALThis tool is equipped with a variable speed control dial (Fig.
Nokia 6300 Manual User Guide
The speed may be controlled during operation by presetting the dial in any one of ten positions.OPERATING SPEEDSThe Dremel Multi-Max consists of an AC universal motor and oscillating mechanism to perform applications such as cutting, grout removal, scraping, sanding and more.The Dremel Multi-Max has a high oscillating motion of 10,000 - 21,000 opms. The high speed motion allows the Dremel Multi-Max to achieve with excellent results. The oscillating motion allows the dust to fall to the surface rather than slinging particles into the air.To achieve the best results when working with different materials, set the variable speed control to suit the job (See Speed Chart on Page 10 for guidance).
Dremel Multi Max Mm45 Manual
To select the right speed for the accessory in use, practice with scrap material first.NOTE: Speed is affected by voltages changes. A reduced incoming voltage will slow the OPM of the tool, especially at the lowest setting.
If your tool appears to be running slowly, increase the speed setting accordingly. The tool may not start at the lowest switch setting in areas where outlet voltage is less than 120 volts.
Simply move the speed setting to a higher position to begin operation.The variable speed control settings are marked on the speed control dial. The settings for approximate OPM’s are:Switch SettingSpeed Range/min (OPM)210,011,013,016,0019,000-21,000You can refer to the charts on next page to determine the proper speed, based on the material and accessory being used. These charts enable you to select both the correct accessory and the optimum speed at a glance.FIG.
6-9-VARIABLE SPEEDCONTROL DIALDM 07-08.qxp 8/6/08 2:15 PM Page 9.
